11 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/SIM2000
Please note: This documentation may contain further technical data.
11.1
Features
Feature Parameter
Task data recording, evaluation, and archiving
Supported devices/excerpt 2D and 3D cameras from SICK or based on the GigE machine
vision standard, encoders, code readers, SICK LiDAR scanners
Technology Embedded hardware architecture:
•
8-core ARM Cortex-A72 CPU with NEON accelerator
•
FPGA for I/O handling
•
Dedicated fieldbus controller
Software:
•
Can be programmed within the SICK AppSpace environment
•
SICK Interface & Algorithm API
Random Access Memory 4 GB DDR4
Flash memory 7 GB eMMC, of which 5 GB are available for applications
memory card (optional) Industry-grade microSD memory card (flash card), max. 32 GB
Programming software SICK AppStudio
Sensor data processing based on SICK Interface & Algorithm API
11.2 Interfaces
Feature Parameter
User interfaces Web server (GUI), SICK AppStudio (programming), SICK AppMan‐
ager (app installation, firmware update)
Data storage and retrieval Image and data logging via
MicroSD memory card, internal RAM, and external FTP
SERIAL (RS-232 / RS-422 / RS-485)
Quantity 1, also configurable as an encoder port
Function RS-232 / RS-422 / RS-485 / INC-In/Out
Maximum data transmis‐
sion rate
RS-232: 115.2 kBaud
RS-422: 2 MBaud
RS-485: 2 MBaud
INC (Incremental)
Quantity 1, also configurable as RS-422
Function Incremental encoder (In/OUT), RS-422 interface
Maximum frequency 2 MHz
FIELDBUS (fieldbus)
Quantity 2
Function Ethernet-based fieldbus
TECHNICAL DATA 11
8023297//2021-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | SIM2000
39
Subject to change without notice
