Feature Parameter
Data transmission rate 10/100 Mbit/s
Protocol ProfiNet, Ethernet/IP, EtherCAT
ETHERNET
Quantity 4
Function Data output, configuration, firmware update, 4 x PoE PSE 12 W
max.
Data transmission rate ETH1 – 4: 0.01; 0.1; 1; 2.5 Gb/s with PoE
Protocol TCP/IP, FTP (image transfer), OPC-UA, MQTT, GigE machine vision/
GenICAM
CAN
Quantity 1
Function SICK CAN sensor network (master/slave, multiplexer/server), ter‐
mination controllable via app
Data transmission rate 20 kbit/s ... 1 Mbit/s
Protocol CSN (SICK CAN sensor network)
IO-Link
Quantity 4 (SENSOR S1 to S4)
Function IO-Link Master V1.1
Data transmission rate max. 230 kBaud
Digital inputs/outputs
I/O Inputs: 2 opto-decoupled, max. frequency: 30 kHz
Inputs/outputs: 2 (configurable), max. frequency: 30 kHz
SENSOR S1-S4 Inputs: 1 each, max. frequency: 30 kHz
Inputs/outputs: 1 each (configurable), max. frequency: 30 kHz
SENSOR S5-S6 Inputs: 1 each, max. frequency: 10 kHz
Inputs/outputs: 2 each (configurable), max. frequency: 30 kHz
USB USB 2.0 (Micro-B) for configuration, diagnostics, firmware update
11.3 Mechanics and electronics
Feature Parameter
Control elements 1 selector switch, 1 function button (under the servicing panel)
Electrical connection I/O: 1 x M12, 8-pin female connector, A-coded
POWER: 1 x M12, 4-pin male connector, T-coded
INC: 1 x M12, 8-pin female connector, A-coded
SERIAL: 1 x M12, 8-pin female connector, A-coded
FIELDBUS: 2 x M12, 4-pin female connector, D-coded
CAN: 1 x M12, 5-pin female connector, A-coded
SENSOR S1–S4, IO-Link master: 4 x M12, 5-pin female connector,
A-coded
SENSOR S5–S6: 2 x M12, 5-pin female connector, A-coded
Ethernet with POE: 4 x M12, 8-pin female connector, X-coded
USB: Micro-B
Supply voltage 24 V DC, ± 10% SELV in accordance with EN 61010, also applies
to digital inputs
Operating current Must be limited by external power supply unit to max. 8 A
Power consumption Typ. 45 W, without connected sensors
Power output Max. 140 W total (all connections)
11 TECHNICAL DATA
40
O P E R A T I N G I N S T R U C T I O N S | SIM2000 8023297//2021-06-22 | SICK
Subject to change without notice
