Parameter
Minimum Typical Maximum
Current consumption (with picked-up
r
elay)
1)
– 220 mA 270 mA
Switching load in accordance with
cULus
AC 30 V Class 2
DC 60 V Class 2
External fuse protection (supply volt‐
a
ge U
B
)
0.4 A – 8 A
Safety outputs 2 safety relays with one normally open contact each
Off and on delay
2)
1 activated actuator
2 ac
tivated actuators
3 activated actuators
4 activated actuators
–
–
–
–
–
–
–
–
210 ms
290 ms
370 ms
450 ms
Switching current (relay outputs)
3)
at switching voltage 1 … 60 V
4)
a
t switching voltage 17 … 30 V
at switching voltage 17 … 230 V
1 mA
15 mA
15 mA
–
–
–
300 mA
6000 mA
1500 mA
External fuse protection (safety cir‐
c
uit) in accordance with IEC 60269-1
6 A gG or miniature circuit-breaker 6 A with characteris‐
tic B or C
Utilization category in accordance
w
ith IEC 60947-5-1
AC-12 300 mA 60 V/DC-12 300 mA 60 V
AC-12 6 A 30 V/DC-12 6 A 30 V
AC-15 1.5 A 230 V/DC-13 1.2 A 24 V
Rated insulation voltage U
i
– – 250 V
Rated impulse withstand voltage U
im
p
– – 4 kV
Conditional rated short-circuit current 100 A
Vibration resistance In accordance with IEC 60947-5-2
Mechanical switching operations
(r
elay)
10 × 10
6
Discrepancy time for switching points of both relays
2 activated actuators
4 activated actuators
–
–
–
–
240 ms
400 ms
Switching delay as from change in
s
tatus
– – 180 ms
Time delay before availability
5)
– 10 s 12 s
Dwell time
6)
3 s – –
Switching frequency
7)
– – 0.25 Hz
Repeatability R in accordance with
IE
C 60947-5-3
≤ 10 %
Application diagnostic outputs (diagnostics DIA, signaling contact OUT, semiconductor output,
p-
switching)
8)
Output voltage
Load capability
0.8 × U
B
–
–
–
U
B
20 mA
Test input, reset input
LOW
H
IGH
Input current HIGH
0 V DC
15 V DC
5 mA
–
–
8 mA
2 V DC
U
B
10 mA
Operation with manual reset
Actuation time of reset button 250 ms
TECHNICAL DATA 11
