WTF12L-xxxxx2xx：
0
2
(0.08)
100
(3.94)
50
(1.97)
0
y
x
Minimum object height in mm (inch)
Example:
Reliable detection of the object
Background
Distance in mm (inch)
Recommended sensing range for
the best performance
10
(0.39)
8
(0.31)
6
(0.24)
4
(0.16)
150
(5.91)
y
x
White background (90 % radiance factor)
Distance of sensor to background x = 80 mm
Required minimum object height y = 0.7 mm
For all objects regardless of their colors
6%/90%
90%/90%
2
1
6%/6%
90%/6%
插图 6: WTF12L-xxxxx2xx
0
Distance in mm (inch)
20 150
35
D
C
A B
BluePilot
E
F
Recommended sensing range for the best performance
100
(3.94)
50
(1.97)
150
(5.91)
插图 7: WTF12L-xxxxx2xx
A
最小触发感应距离，单位：mm
B
最大触发感应距离，单位：mm
C
视野
D
前景抑制功能开关阈值的设置范围
E
触发感应距离显示
F
按转元件
蓝色
为实现最佳性能而建议的触发感应距离范围
操作指南
8027710/2022-04-12 | SICK 操作 指 南 | WTF12L/WTF12V
217
如有更改，恕不另行通知
