Check the application conditions: Compare distance between sensor and background,
minimal object height as well as remission capability of background and object with the
associated diagram (see figure 8, page 35) (x = sensing range, y = minimum object
height). Remission factor: 6% = black 1, 90% = white 2 (referring to standard white as
per DIN 5033).
WTF12L-xxxxx1xx:
0
2
(0.08)
100
(3.94)
200
(7.87)
300
(11.81)
0
y
x
Minimum object height in mm (inch)
Example:
Reliable detection of the object
Background
Distance in mm (inch)
Recommended sensing range for
the best performance
12
(0.47)
10
(0.39)
8
(0.31)
6
(0.24)
4
(0.16)
400
(15.75)
y
x
White background (90 % radiance factor)
Distance of sensor to background x = 150 mm
Required minimum object height y = 1.2 mm
For all objects regardless of their colors
6%/90%
90%/90%
2
1
6%/6%
90%/6%
Figure 4: WTF12L-xxxxx1xx
0
Distance in mm (inch)
80 350
100
D
C
A B
BluePilot
E
F
Recommended sensing range for the best performance
100
(3.94)
200
(7.87)
300
(11.81)
400
(15.75)
Figure 5: WTF12L-xxxxx1xx
A Sensing range min. in mm
B Sensing range max. in mm
C Visibility range
D Adjustable switching threshold for foreground suppression
E Sensing range indicator
F Teach-Turn adjustment
Blue Recommended sensing range for the best performance
