sidhil Solite UK - 9.8 Extending the Bed

24
To Extend the Bed Frame
• Flatten and lower the bed to its minimum
height.
• Apply the brakes to the head end of the
bed and ensure the foot end brakes are not
applied.
• Unclip the foot end actuator cable from
the bed frame cable clip (to prevent over
extending the cable).
• Loosen the 4 hand wheels at the foot end of
the bed (2 per side).
• Whilst holding the foot end near the locking
collars pull the bed extension out until it
reaches the end stop.
• Re-tightenallthehandwheelsandsecurethe
actuator cable back into its clip.
To Extend the Platform
• Loosenby3-4turns,thetwohandwheels
located on the platform section.
• Slide the platform extension out to the
correct length to suit the mattress and
extension block being used (if a Sidhil
mattress and extension are being used then
it may be pulled out to the end stops).
• Re-tightentheextensionhandwheels(take
care not to over tighten as damage to the
extension tubes may occur).
Returning the bed to its original state is a reverse of the above.
The platform extension must be returned to its shortened length before
reducing the main bed frame extension or severe damage could be caused
to the platform extension.
Bed frame hand wheels
Platform hand wheel
Caution
9.8 Extending the Bed
