MHS400 smart Installation and operating instructions
05.2017
4. Scope of delivery
Number
of pieces
Size by slide drive
MHS400 smart
Size range in mm Colour
1 Scheme A, size 1 (one slide drive each on left or right) 2144 – 2794
White RAL 9003
Silver RAL 9006
1 Scheme A, size 2 (one slide drive each on left or right) 2795 – 4099
1 Scheme A, size 3 (one slide drive each on left or right) 4100 – 6666
1 Scheme C, size 1 (one slide drive each on left and right) 4284 – 5584
1 Scheme C, size 2 (one slide drive each on left and right) 5585 – 8194
1 Scheme C, size 3 (one slide drive each on left and right) 8195 – 13328
Pos.
Number
of pieces
Contents of slide drive SA carton Version
A C
1a 1 – Scheme A - Slide drive SA
Including 24 V power supply
1b – 2 Scheme C - Slide drive SA
2 1 2 Catch For slide drive SA
3 1 2 Catch base For lift & slide sash top
4 1 2
Packer (2.5 / 5 / 8/ 10 mm thick depending on profile
system)
For catch on lift & slide sash top
5 1 2 Cover cap M For catch
6
1 1 Cover profile SA
For slide drive SA
– 2 Cover profile SA with profile connector
7 1 1 Cover cap SA left For cover profile SA
8 1 1 Cover cap SA right For cover profile SA
9 1 2 Sash cable (flat ribbon cable, 6-wire) For slide drive SA
10 12 24 Cable holder Clip-on or screw-on
11 1 1 Network connection cable with Euro plug On slide drive SA, 5 m cable length
12 1 1 Terminal board (optional) For connecting light curtain*
13 1 1 Installation and operating instructions
*e.g. if the result of the risk analysis requires a light curtain
Pos. Pieces Contents of lift drive HA carton Version
14 1 2 Lift drive HA
15 1 2 Fixing plate HA For lift drive HA
16 1 2 Cover cap HA top For lift drive HA
17 1 2 Cover cap HA bottom For lift drive HA
18 4 8
M5 x 10 mm fixing screws
(inc. washers)
For fixing plate lift drive HA
19 2 4
M4 x 25 mm fixing screws
(inc. washers)
For cover cap HA top
20 1 2
M5 x 19 mm fixing screw
with M5 square nut
For cover cap HA bottom
21 1 1
Emergency operating handle Hexagon wrench WAF 8
