Technical specifications
6.1 Technical specifications
Analog input module AI 4xRTD/TC 2-/3-/4-wire HF (6ES7134-6JD00-0CA1)
Manual, 02/2014, A5E03573289-AD
43
6ES7134-6JD00-0CA1
•
Internal reference junction
Yes; with BaseUnit type A1
•
Reference channel of the group
Yes
•
Number of reference channel groups
4; group 0 to 3
•
Fixed reference temperature
Yes
Resistance thermometer (RTD)
Maximum permissible input voltage for voltage input
(destruction limit)
30 V
Technical unit for temperature measurement
°C/°F/K
Cable length
Cable length shielded, max.
200 m; 50 m for thermocouples
Analog value generation
Measuring principle
Integrating (sigma-delta)
Integration and conversion time/resolution per channel
Resolution with overrange (bit including sign), max.
16 bit
Integration time configurable
Yes
Basic conversion time including integration time, ms
•
Additional processing time for wire break check
2 ms; in the resistance thermometer,
resistor, and thermocouple areas
•
Additional wire break check of the power line
2 ms; for 3-/4-wire transducer
(resistance thermometer and
resistor)
Interference voltage suppression for interference frequency f1
in Hz
16.6 / 50 / 60 Hz
Conversion time (per channel)
180 / 60 / 50 ms
Smoothing of the measured values
Configurable
Yes
Setting: None
Yes
Setting: Weak
Yes
Setting: Medium
Yes
Setting: Strong
Yes
Sensors
Wiring the signal transmitters
For voltage measurement
Yes
for resistance measurement with 2-wire connection
Yes
for resistance measurement with 3-wire connection
Yes
for resistance measurement with 4-wire connection
Yes
Errors/accuracies
Linearity error (in relation to input range), (+/
-) ± 0.01%; +/- 0.1% for resistance
thermometer and resistor
Temperature error (in relation to input range)
± 0.0009%/K; +/- 0.005%/K for
thermocouple
Crosstalk between inputs, min.
-50 dB
Repeat accuracy in settled state at 25 °C (in relation to input
range), (+/-)
± 0.05%
