fhis instruction manual contains directions
for using the 2000 sound film projector
with 12-watt reproduction amplifier for
showing 16-mm optical and magnetic
sound fi I m. It is intended as a supple-
ment to the main instruction manual for
the "silent" Siemens 2000 projector.
2
General
When reading the instruction manual, please
unfold page 8 and consult Fig. 1.
This illustration shows the 2000 projector
with an optical sound head unit and a fully
transistorized 12-watt reproduction ampli-
fier. Fig. 4 illustrates a sound head unit also
capable of reproducing magnetic fi I m.
Projector and amplifier are connected me-
chanically and electrically by a plug-in con-
nection, detachable at any time. The ampli-
fier (Fig. 2) may thus also be used sepa rat ely
for pick-up or microphone transmission.
Connection to mains is effected by the
supply cable S 27 439-A 5-A 1.
Fig . 3 Voltage selector
b a
