Siemens 353 User Manual

Data Mapping UM353-1B
April 2012
6-14
Analog Indicator [ODA]
Code
R/W Description Range Register (MB)
L#TAG R Loop Tag 12 ASCII Char 45451+100(#-1)
L#P1T R Process 1 Tag 6 ASCII Char 45457+100(#-1)
L#P1U R/W Process 1 Units 6 ASCII Char 45460+100(#-1)
L#P2T R Process 2 Tag 6 ASCII Char 45463+100(#-1)
L#P2U R/W Process 2 Units 6 ASCII Char 45466+100(#-1)
L#P3T R Process 3 Tag 6 ASCII Char 45469+100(#-1)
L#P3U R/W Process 3 Units 6 ASCII Char 45472+100(#-1)
L#P4T R Process 4 Tag 6 ASCII Char 45475+100(#-1)
L#P4U R/W Process 4 Units 6 ASCII Char 45478+100(#-1)
L#Q1N R Quickset Hold 1 Name 8 ASCII Char 45481+100(#-1)
L#Q1U R/W Quickset Hold 1 Units 6 ASCII Char 45485+100(#-1)
L#Q2N R Quickset Hold 2 Name 8 ASCII Char 45488+100(#-1)
L#Q2U R/W Quickset Hold 2 Units 6 ASCII Char 45492+100(#-1)
L#Q3N R Quickset Hold 3 Name 8 ASCII Char 45495+100(#-1)
L#Q3U R/W Quickset Hold 3 Units 6 ASCII Char 45499+100(#-1)
L#Q4N R Quickset Hold 4 Name 8 ASCII Char 45502+100(#-1)
L#Q4U R/W Quickset Hold 4 Units 6 ASCII Char 45506+100(#-1)
(spares) ($0000) 45509-45550+100(#-1)
Discrete Indicator [ODD]
Code
R/W Description Range Register (MB)
L#TAG R Loop Tag 12 ASCII Char 45451+100(#-1)
L#I0T R Input 0 Tag 6 ASCII Char 45457+100(#-1)
L#I1T R Input 1 Tag 6 ASCII Char 45460+100(#-1)
L#I2T R Input 2 Tag 6 ASCII Char 45463+100(#-1)
L#I3T R Input 3 Tag 6 ASCII Char 45466+100(#-1)
L#I4T R Input 4Tag 6 ASCII Char 45469+100(#-1)
L#I5T R Input 5 Tag 6 ASCII Char 45472+100(#-1)
L#I6T R Input 6 Tag 6 ASCII Char 45475+100(#-1)
L#I7T R Input 7 Tag 6 ASCII Char 45478+100(#-1)
L#I8T R Input 8 Tag 6 ASCII Char 45481+100(#-1)
L#I9T R Input 9 Tag 6 ASCII Char 45484+100(#-1)
L#IAT R Input A Tag 6 ASCII Char 45487+100(#-1)
L#IBT R Input B Tag 6 ASCII Char 45490+100(#-1)
L#ICT R Input C Tag 6 ASCII Char 45493+100(#-1)
L#IDT R Input D Tag 6 ASCII Char 45496+100(#-1)
L#IET R Input E Tag 6 ASCII Char 45499+100(#-1)
L#IFT R Input F Tag 6 ASCII Char 45502+100(#-1)
(spares) ($0000) 45505-45550+100(#-1)
Discrete Indicator [ODP] - (V2.2)
Code
R/W Description Range Register (MB)
L#TAG R Loop Tag 12 ASCII Char 45451+100(#-1)
L#G1Tag R Group 1 Tag 6 ASCII Char 45457+100(#-1)
L#G1P1T R Group 1 PB1 Tag 6 ASCII Char 45460+100(#-1)
L#G1P2T R Group 1 PB2 Tag 6 ASCII Char 45463+100(#-1)
L#G1SAT R Group 1 Switch Position A Tag 6 ASCII Char 45466+100(#-1)
L#G1SMT R Group 1 Switch Position M Tag 6 ASCII Char 45469+100(#-1)
L#G1F1T R Group 1 Feedback 1 Tag 6 ASCII Char 45472+100(#-1)
L#G1F0T R Group 1 Feedback 0 Tag 6 ASCII Char 45475+100(#-1)
L#G2Tag R Group 2 Tag 6 ASCII Char 45478+100(#-1)
L#G2P1T R Group 2 PB1 Tag 6 ASCII Char 45481+100(#-1)
L#G2P2T R Group 2 PB2 Tag 6 ASCII Char 45484+100(#-1)
L#G2SAT R Group 2 Switch Position A Tag 6 ASCII Char 45487+100(#-1)
L#G2SMT R Group 2 Switch Position M Tag 6 ASCII Char 45490+100(#-1)
L#G2F1T R Group 2 Feedback 1 Tag 6 ASCII Char 45493+100(#-1)
L#G2F0T R Group 2 Feedback 0 Tag 6 ASCII Char 45496+100(#-1)
