UM353-1B Configuration Overview
April 2012
2-7
LOOP
X
|
ENTER
EXIT
CONF
<>
|
|
STORE
STATION
X
FCO
X
X
STORE
STA TN
MMC
98765432
X
<>
SECURITY
X
<>
CAL
X
<>
TC2053
Alphanumeric Display
325.80
Numeric Display
Configuration Pushbutton
~008
Display with changeable value (turn Pulser knob)
<>
Turn Pulser to select new parameter or value (move horizontally across map)
X Use Step Up or Step Down pushbutton (move vertically across map)
Key:
<+>
Turn Pulser to select additional menu items (items not shown)
MG00519b
<>
x
<>
ETHERNET
CLOCK
X
x
CONFIGS
<>
<>
NEW FILE
<>
NEW DIR
<
Dir Name(s)
>
STORE
<> <>
|
|
DIR 1
CONFIG 1
LOAD STORE
|
STORE
REMOVE WP
X
<>YES
NO
|
STORE
|
STORE
NEW FILENEW DIR
|
STORE
|
STORE
DIR 1
CONFIG 1
(1)
(2)
(2)
(3,6)
(3,6)
(3,6)
(3,6)
(4)
(5)
|
FileErr1
MMC will display only when a valid MultiMediaCard is installed in the socket on the Controller board.
If one or more .V3C files or sub-directories exist, the name of the first file or sub-directory listed in the directory will be
displayed. Additional files or sub-directories can be displayed by turning the pulser knob clockwise. If no files exist OR
the pulser is turned counterclockwise, NEW FILE or NEW DIR (respectively) will be displayed.
This is the default directory or file name. A unique name of up to 8 characters can be stored.
When storing a file with the write protect file attribute is set, this additional menu option will be presented.
When loading a file, if an error is found, an error code will display.
A directory or file can be renamed
before it is stored. To change a displayed directory name or file name, use the left/right
arrow keys to select the character to change, then rotate the pulser knob to select a new character.
Stored files and directories can be deleted and renamed at a PC running Windows Explorer or i|config.
Press STORE to save a new or edited configuration to the root directory of the MMC. The default file name will be the
serial number of the controller (8 characters plus a .V3C extension; the extension is not displayed at the 353
faceplate). A previously saved file will be overwritten.
Notes:
(1)
(2)
(3)
(4)
(5)
(6)
<+>
File Names
Figure 2-2 MultiMediaCard Road Map

