Siemens 6SE7036-1EE85-1AA0 - Page 171

09.02 Parameter List
Siemens AG 6SE7087-6AK85-1AA0
5-13
Rectifier/Regenerating Unit Operating Instructions
PNU
* : Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
P316 DC V-Reg +Limit
Positive threshold for the dead band of the setpoint/actual-value difference
of the U
d
controller
A setpoint/actual-value deviation signal for the DC link voltage is not applied
to the U
d
controller until the deviation of the DC link voltage exceeds
the
value set here.
RDS parameter
PNU=13CHex; Type=O2; Scaling: 1Hex
=
∧
0.01
0.00 to 100.00
[%] of 1.35
*
P071
4
0.01
3/ BR
3/ BR
P317 DC V-Reg -Limit
Negative threshold for the dead band of the setpoint/actual-value difference
of the U
d
controller
A setpoint/actual-value deviation signal for the DC link voltage is not applied
to the U
d
controller until the deviation of the DC link voltage drops below
the
value set
RDS parameter
PNU=13DHex; Type=I2; Scaling: 1Hex
=
∧
0.01
-100.00 to 0.00
[%] of 1.35
*
P071
4
-1.00%
3/ BR
3/ BR
P318 DC V(set,red)
DC link voltage setpoint with active DC link reduction (i.e. upon request for
U
d
reduction via control word 1, Bit 11= 1 (control word-source selection via
P571) or for internally generated U
d
reduction command in event of
released current-dependent U
d
reduction (P323= 1))
With parameter setting P318 > 100.00 %, the Ud controller
of the E unit or
the E/R unit can be operated at full signal level
with the recovery direction
blocked (P076= xx1).After precharging, this leads to the control angle α=0.
RDS parameter
PNU=13EHex; Type=O2; Scaling: 1Hex
=
∧
0.01
0.00 to 160.00
[%] of 1.35
*
Supply
voltage at the
rectifier bridge
4
80.00
3/ ABR
3/ ABR
P319 DC V(set,red)Hys
Hysteresis for Ud < Ud(set,red)
(message "Ud reduced")
RDS parameter
PNU=13FHex; Type=O2; Scaling: 1Hex
=
∧
0.01
0.00 to 100.00
[%] of 1.35xP071
4
6.00%
3/ ABR
3/ ABR
P320 Smooth Load Amps
Smoothing time for feedforward load current injection
RDS parameter
PNU=140Hex; Type=O2; Scaling: 1Hex
=
∧
1
0 to 9999
[ms]
4
5
3/ BR
3/ BR
P321 DC CurrThresVred
Current threshold for current-dependent DC link reduction
If I
d
(averaged over 3 current crests) falls below
the value set here, the U
d
setpoint is reduced over a ramp (discharge time P330 active) to the value in
accordance with P318 when current-dependent U
d
reduction (P323=1) is
released.
RDS parameter
PNU=141Hex; Type=O2; Scaling: 1Hex
=
∧
0.01
0.00 to 100.00
[%]
4
30.00
3/ BR
3/ BR
P322 DC CurrHyst.Vred
Hysteresis for current-dependent DC link voltage reduction
If I
d
(averaged over 3 current crests) exceeds
the sum of P321 and the
value set here, the U
d
setpoint increases over a ramp (precharge time P329
active) to the value 1.35
*
U
line,feed
when current-dependent U
d
reduction
is released (P323=1).
RDS parameter
PNU=142Hex; Type=O2; Scaling: 1Hex
=
∧
0.01
0.00 to 100.00
[%]
4
20.00
3/ BR
3/ BR
