Siemens 6SE7036-1EE85-1AA0 - Selecting the Source for Control Word 1 (Bit 8-15)

09.02 Start-Up
Siemens AG 6SE7087-6AK85-1AA0
4-15
Rectifier/Regenerating Unit Operating Instructions
4.3.1.1.4 Selecting the source for control word 1 (bit 8-15)
Bit
8 9 10 11 12 13 14 15
Selection P. basic setting
568.1 569.1 571.1 572.1 573.1 574.1 575.1
Selection P. reserve setting
568.2 569.2 571.2 572.2 573.2 574.2 575.2
Value
Source
0000 Constant value = 0
xG/R xG/R
xG/R
x
xG/R
0001 Constant value = 1 x
xG/R xG/R
xG/R
1001 CUR, BE1, -X101:9 x x x x x x x
1002 CUR, BE2, -X101:10 x x x x x x x
1003 CUR, BE3, -X101:11 x x x x x x x
1004 CUR, BE4, -X101:12 x x x x x x x
1005 CUR, BE5, -X101:23 x x x x x x x
1010 PMU
2001 SST1 (PMU -X300 or -X100:1...5)
Word1
x x x x x x x
2004 SST1 (PMU -X300 or -X100:1...5)
Word4
OPTIONS
3001 CB/TB (Word1) x x x x x x x
3004 CB/TB (Word4)
4101 SCI 1 and 2, Slave 1,BE1 x x x x x x x
4102 BE2 x x x x x x x
... Consecutively to x x x x x x x
4110 BE10 x x x x x x x
4111 only SCI 2, Slave 1,BE11 x x x x x x x
4112 BE12 x x x x x x x
... Consecutively to x x x x x x x
4116 BE16 x x x x x x x
4201 SCI 1 and 2, Slave 2,BE1 x x x x x x x
4202 BE2 x x x x x x x
... Consecutively to x x x x x x x
4210 BE10 x x x x x x x
4211 only SCI 2, Slave 2,BE11 x x x x x x x
4212 BE12 x x x x x x x
... Consecutively to x x x x x x x
4216 BE16 x x x x x x x
4501 SCB-SST (USS /Peer-t-Peer) Word1 x x x x x x x
4504 SCB-SST (USS /Peer-t-Peer) Word4
6001 SST2 (PTP1, A2-X117:1..5) Word 1 x x x x x x x
... Consecutively to x x x x x x x
6005 SST2 (PTP1, A2-X117:1..5) Word 5 x x x x x x x
x: Value can be assigned for the selection parameters
Factory setting: xG: for basic setting with P077=0
xR: for reserve setting with P077=0
