7XT7100-0*A00/DD English
C53000-B119U-C128-1 21
Connection Example
Figure 9 Connections for rotor earth fault protection (for excitation voltages < 850 V)
Earthing of the generator
shaft
Coupling unit
7XR604
7UM515
or 7UM62
Controller unit
7XT71
U
Con-
U
Mea
