Siemens 7XT71 Series User Manual

7XT7100-0*A00/DD English
C53000-B119U-C128-1 15
Technical Data
Auxiliary voltage
1
) Switch S1 in position "115 V" (Default setting)
2
) Switch S1 in position "230 V"
Power consumption approx. 5 VA
Output voltage U
Output
short-circuit-proof
Terminals 25, 27 ± 50 V (± 4V)
max. output current 20 mA
Output voltage U
Control
short-circuit-proof
Terminals 19, 21 < 15 V
max. output current 2 mA
Output voltage U
Meas
short-circuit-proof
Terminals 15, 17 < 15 V
max. output current 2 mA
Frequency of polarity reversal
Setting range 0.5 to 4.0 Hz ± 10 %
convertible with switch S2
Default setting 1.5 Hz ± 10 %
Terminals
7, 9 7,11 7, 9
Nominal auxiliary a.c. voltage
U
aux. ac
50/60 Hz
100, 110, 115 Vac
1
) 120, 125 Vac
1
) 230 Vac
2
)
Permissible variations ac
Temperature in range
-5 to +40 °C
-5 to +55 °C
80 to 132 V~
80 to 127 V~
96 to 144 V~
96 to138 V~
184 to 264 V~
184 to 253 V~
