Electrical data
ፌߛۉუ kV 3.6
1)
7.2
1)
12
2)
Rated voltage kV
ܮۨ߾ೕఱ๴ۉუ kV 24 32 28
Rated power frequency withstand voltage kV
జ၍ፌٷඤ࿘ۨۉୁ kA 50/1s,40/4s 50/1s,40/4s 50/1s,40/4s
Rated short-time current of the busbar,max kA
ઍ၍ඤ࿘ۨۉୁ kA/1s 8 8 8
( ࿮ߛቼ܏ඹଉ၌ୁභ܏ഗፕᆩ้ )
Rated short-time current of the feeder kA/1s
(without current limitation through H.V.HRC fuses)
ܮۨፌٷజ၍ރኵۉୁ kA 125 125 125
Rated peak withstand current of the busbar,max kA
ߛቼ܏ඹଉ၌ୁභ܏ഗڦᇨ೺܌ୟ܏ۉୁ kA <50 <50 <50
Cut-off current ID of H.V.HRC fuses kA
ܮۨፌٷజ၍ۉୁ A 4000 4000 4000
Rated current of the busbar, max A
ܮۨઍ၍ۉୁ A 400 400 400
Rated current of the feeder, max A
ፌٷܮۨ܏ࠀ୲ā Rated breaking-power,max
ۉۯ Motor kW 1600 3200 6500
Վუഗ Transformer kVA 1600 3200 3200
ۉඹഗፇ Capacitor kVAr 1600 3500 5000
ۉඹഗፇڦፌٷ܏ۉୁ A 250 250 250
Capacitor breaking capacity A
ፌٷሎႹᆥୁ kA 10 10 10
Max.permissible inrush current kA
ፌٷ֡ፕೕ୲ ֡ፕْຕ / ၭ้ 1200 1200 1200
Frequency of operation Op.cycles/h
ႁ๱ం ֡ፕْຕ 3×10
6
3×10
6
1×10
6
Mechanical life Op.cycles
ۉ๱ం ֡ፕْຕ 1×10
6
1×10
6
1×10
6
Electrical endurance Op.cycles
ࢇቄࠀ୲ AC/DC W 650 650 650
Making capacity AC/DC W
ԍ׼ࠀ୲ W 90 90 90
Holding power W ā ā ā
؅٫
Dimensions
܈ Width
௅߲࣮ୟ mm 400 400 400
Per panel mm
௅߲ࡋ༹ ( ມ࣮ୟ * mm 800 800 800
2 Panels mm
ߛ܈ mm 2050 2050 2050
Height mm
ศ܈
3)
mm 1650 1650 1650
Depth mm
1) ߾ೕఱუߵዐࡔՔጚ
1DžPower frequency withstand voltage according to Chinese standard
2Dž߾ೕఱუߵ IEC Քጚ
2DžPower frequency withstand voltage according to IEC standard
3Džසᇑศ܈ྺ 1775 ࡹ௝ڦ 8BK20 ࠲ࡋ೔ጎLjሶ 8BK30 ࡋټᆶ޹ࡋăᅜՍ؅٫ᇑ 8BK20 ࡋᅃዂ
3) When switchgear 8BK30 is aligned together with 8BK20 whose depth is 1775mm, an additional panel is attached to 8BK30 in order to
keep the same dimension
ݞۉᅜݞᅴ࿿ڦൔ෇
( ߛუ๪ோ࠲Կ )
࠲ࡋ ݞࢺڪ
Ԩݛӄ IP4X ߵ DIN VDE 0670/
IEC298  IP40 ߵ DIN
40 050/IEC529
༬๺ݛӄ IP41LjIP50  IP51 ߵ DIN/
40 050/IEC 529
՗௬ԍࢺ
ࡋമߒӱևǖ࣍ᄟຏኬݹ఍಩ཱDŽRAL 7032Dž
ഄ໲ߒӱևǖඤ܆ႋۉ܆ܛࣅDŽࣜ෥Dž
؅٫ǖׂ೗ຫ௽ກ 006
ዘଉǖሀ 700 ࠅুDŽມ࣮ୟࡋDž
ැႴᄲକ঴ 3TL6 ኈথةഗ߸ၘဦڦጨଙLj൩֖ለ၎࠲ڦ
ຫ௽ກă
Protection against electric shock and against ingress of
solid foreign bodies
(door of HV compartment closed)
Panel Degree of protection
Basic IP4X according to DIN VDE 0670/
Version IEC298 or IP40 according to
DIN 40 050/IEC529
Special IP41, IP50 or IP51
Version according toDIN/10 050/IEC 529
Surface protection
Sheet-steel parts of front side: epoxy resin powder coating
(RAL 7032). Other sheet-steel parts: hot-galvanized or
electro-plated and yellow passivated
Dimensions: see Catalog 006
Weight: approx.700kg (double panel)
For details on the 3TL6 vacuum contactor refer to the
associated operating instructions
