Siemens 8DJH Series - Page 56

Description
56 Revision 03 * INSTALLATION AND OPERATING INSTRUCTIONS 8DJH * 500-8067.9
10-12 25 10-17.5 292 30 221 13.25
25 10-17.5 442 30 231 13.25
25 10-24 442 30 006 13.25
250 4 14.5 25 6-12 292 30 004 13.25
25 6-12 442 30 101 13.25
25 10-17.5 292 30 221 13.25
25 10-17.5 442 30 231 13.25
25 10-24 442 30 006 13.25
31.5 6-12 292 30 004 13.31,5
31.5 6-12 442 30 101 13.31,5
31.5 10-17.5 292 30 221 13.31,5
31.5 10-17.5 442 30 231 13.31,5
31.5 10-24 442 30 006 13.31,5
315 4 18.3 31.5 6-12 292 30 004 13.31,5
31.5 6-12 442 30 101 13.31,5
31.5 10-17.5 292 30 221 13.31,5
31.5 10-17.5 442 30 231 13.31,5
31.5 10-24 442 30 006 13.31,5
40 6-12 292 30 004 13.40
40 6-12 442 30 101 13.40
40 10-17.5 292 30 221 13.40
40 10-17.5 442 30 231 13.40
40 10-24 442 30 006 13.40
400 4 23.1 40 6-12 292 30 004 13.40
40 6-12 442 30 101 13.40
40 10-17.5 292 30 221 13.40
40 10-17.5 442 30 231 13.40
40 10-24 442 30 006 13.40
50 6-12 292 30 004 13.50
50 6-12 442 30 101 13.50
50 10-17.5 292 30 221 13.50
50 10-17.5 442 30 232 13.50
50 10-24 442 30 014 13.50
500 4 29 50 6-12 292 30 004 13.50
50 6-12 442 30 101 13.50
50 10-17.5 292 30 221 13.50
50 10-17.5 442 30 232 13.50
50 10-24 442 30 014 13.50
63 6-12 292 30 012 43.63
63 10-24 442 30 014 43.63
630 4 36.4 63 6-12 292 30 012 43.63
80 10-24 442 30 014 43.80
63 6-12 292 30 012 13.63
63 6-12 442 30 102 13.63
63 10-17.5 442 30 232 13.63
80 6-12 292 30 012 43.80
80 6-12 442 30 102 43.80
800 5-6 46.2 63 6-12 292 30 012 13.63
80 6-12 292 30 012 43.80
80 6-12 442 30 102 43.80
Transformer HV HRC fuse
U [kV] S
N
[kVA] u
K
[%] I
1
[A] I
s
[A] U
s
[kV] e [mm] Order no.
