Description
58 Revision 03 * INSTALLATION AND OPERATING INSTRUCTIONS 8DJH * 500-8067.9
15-17.5 630 4 24.3 40 10-17.5 442 30 231 13.40
40 10-24 442 30 006 13.40
50 10-17.5 442 30 232 13.50
50 10-24 442 30 014 13.50
63 10-24 442 30 014 43.63
800 5- 6 30.9 63 10-24 442 30 014 43.63
1000 5-6 38.5 80 10-24 442 30 014 43.80
1250 5-6 48.2 100 10-24 442 30 022 43.100
20-24 50 4 1.5 6.3 10-24 442 30 006 13.6,3
75 4 2.2 6.3 10-24 442 30 006 13.6,3
100 4 2.9 6.3 10-24 442 30 006 13.6,3
125 4 3.6 10 10-24 442 30 006 13.10
160 4 4.7 10 10-24 442 30 006 13.10
200 4 5.8 16 10-24 442 30 006 13.16
250 4 7.3 16 10-24 442 30 006 13.16
315 4 9.2 16 10-24 442 30 006 13.16
20 10-24 442 30 006 13.20
400 4 11.6 20 10-24 442 30 006 13.20
25 10-24 442 30 006 13.25
500 4 14.5 25 10-24 442 30 006 13.25
31.5 10-24 442 30 006 13.31,5
630 4 18.2 31.5 10-24 442 30 006 13.31,5
40 10-24 442 30 006 13.40
800 5-6 23.1 31.5 10-24 442 30 006 13.31,5
40 10-24 442 30 006 13.40
1000 5-6 29 50 10-24 442 30 014 13.50
63 10-24 442 30 014 43.63
1250 5-6 36 80 10-24 442 30 014 43.80
1600 5-6 46.5 100 10-24 442 30 022 43.100
2000 5-6 57.8 On request
U Rated system voltage
S
N
Rated power
U
K
Relative impedance voltage
I
1
Rated current
I
S
Rated current of fuse
U
S
Rated voltage of fuse
e Reference dimension
NOTE!
- For switchgear with rated voltages up to 12 kV, a fuse slide for
HV HRC fuse-links with dimension 292 mm is normally provided.
- 7.2 kV fuse-links with dimension 192 mm as well as 24 kV fuse-links with
dimension 292 mm are not permissible.
Transformer HV HRC fuse
U [kV] S
N
[kVA] u
K
[%] I
1
[A] I
s
[A] U
s
[kV] e [mm] Order no.
