500-8067.9 * INSTALLATION AND OPERATING INSTRUCTIONS 8DJH * Revision 03 71
Installation
ATTENTION!
To install the switchgear or the cables, the cross members can be removed.
Then, the switchgear must not be moved anymore, as there are no braces to guarantee
stability during the movement.
Ö Bring the switchgear to the required position.
Ö Remove the cross members.
Ö Do not move the switchgear as long as the cross members are removed.
Fig. 40: Removing the cable compartment covers a and the cross members s if required
