17 / 50
Siemens Actuators SAS.., SAT.. for valves CE1P4041en
Building Technologies Handling 2015-05-19
6
Observe "Wiring (installation)" (page 18)
7
Observe "Connection terminals"
(page 39)
8 9
max. 1.2 Nm
Before commissioning with the control, check the exact position again; see
"Auxiliary switch", page 21.
First, observe "Special notes on mounting” (page 15).
Scope of delivery
Weather shield ASK39.2 2 UV-proof cable ties
· To protect the actuator from weather effects when used outdoors, the weather
shield must always be fitted. The housing protection IP54 remains unchanged.
· If fitted several times, 2 UV-proof cable ties (700 x 7 mm) must be used when
fitted again.
· The manual adjuster cannot be used when the weather shield is mounted.
