Siemens Actuators SAS.., SAT.. for valves CE1P4041en
Building Technologies Technical data 2015-05-19
SAS.. SAT..
Cable entries SA.. EU:
1 entry Æ 16.4 mm (for M16)
1 entry Æ 20.5 mm (for M20)
SA..U US:
2 entries Æ 21.5 mm for ½“ tube connection
Degree of protection Housing protection IP 54 as per EN 60529
3
)
Mounting position vertical
Insulation class As per EN 60730
Actuators SA..31.. AC 230 V II
Actuators SA..61.. AC / DC 24 V III
Actuators SA..81.. AC / DC 24 V III
Environmental
conditions
Operation IEC 60721-3-3
Climatic conditions Class 3K5
Mounting location Indoors, outdoors
4)
Temperature general -5…55 °C
Humidity (noncondensing) 5…95 % r. h.
Transport IEC 60721-3-2
Climatic conditions Class 2K3
Temperature -25…70 °C
Humidity <95 % r. h.
Storage IEC 60721-3-1
Temperature -15…55 °C
Humidity 5…95 % r. h.
Directives and
Standards
Product standard EN60730-x
Electromagnetic compatibility (Application) For residential, commercial and industrial environments
EU Conformity (CE) CE1T4581xx
5)
RCM Conformity CE1T4581en_C1
5)
UL, cUL AC / DC 24 V
UL 873 http://ul.com/database
Environmental
compatibility
The product environmental declaration CE1E4581
5
)
contains
data on environmentally compatible product design and
assessments (RoHS compliance, materials composition,
packaging, environmental benefit, disposal).
Dimensions See Dimensions (page 42)
Weight Excl. packaging See Dimensions (page 42)
Accessories
6)
Auxiliary switch
ASC10.51
Switching capacity AC 24…230 V, 6 (2) A, floating
External supply line protection See section power supply
US installation, UL & cUL AC 24 V class 2, 5 A general purpose
Data sheet N4581 N4584
1)
Second value: Power consumption in neutral position
2)
AWG = American wire gauge
Wire cross-sectional areas and fuses have to be well-matching, which is the responsibility of the
planner / installer. Observe norm of protection measures - protection against overcurrent:
IEC 60364-4-43:2008 resp. german adoption HD 60364-4-43:2010.
3)
Also with weather shield ASK39.2
4)
Outdoors always with weather shield ASK39.2, housing protection IP54 remains unchanged
5)
The documents can be downloaded from http://siemens.com/bt/download
6)
UL recognized component
