Siemens AG SPR2-310.815.01.07.02 ARCADIS Varic
12.06 CS PS SP
Protocols 53
Page 53 of 64
Medical Solutions
Measuring circuit 0
Fig. 22: Measuring circuit for measuring the protective conductor resistance for units that are
disconnected from power, in compliance with DIN VDE 0751-1/2001-10, Fig. C2.
Pos. 1 Measurement setup (measuring device)
Pos. 2 System
Pos. 3 Application part (if applicable)
Comments: 0
Tab. 8
Date Comments Name Signature
