Siemens BS-240 - 1.2 Technical Data

12
A30808-X3247-L14-2-7618
Technical Description (TED:BSS)
BS-240/241
Information
Base Station System
1.2 Technical Data
The BS-240/241 family with 24 transceivers can be supplied in the following versions:
– A BS-240 for indoor installation.
– A BS-241 for outdoor installation (also equipped with: integrated power supply,
battery, microwave equipment, integrated link equipment, heat exchanger and cross
connector).
BS-240/241 consist in a split BTS architecture, with:
- 1 Base Rack
- Up to 2 Extension Racks
- Up to 2 Service Racks (Service1 or Service2).
Characteristics BS-240 (indoor) BS-241 (outdoor)
Max. TRX per BTSE 24 24
(in more than one Rack)
Max. TRX per cell 24 24
(in more than one Rack)
Dimensions (mm) (HxWxD) 1600x600x450 (5’3”x2’x1’6”) 1750x700x650 (5’9”x2’4”x2’2”)
(Base Racks) (incl. Plinth)
Volume net 432 l 705 l
796 l (incl. Plinth)
Maximum power consumption 1600 W 1750 W
Weight of Basic Rack empty ca.60 kg (132 Lbs) ca.60 kg (132 Lbs)
Weight of Shelter empty ca.110 kg (242 Lbs)
Weight of Service1 Rack equipped with: - 1 Frame AC/DC incl. 6 AC/DC Modules (ca. 27 kg/60 Lbs)
- 1 Frame for Battery incl. 1Battery (48V / 85 Ah) (ca. 140 kg/309
Lbs)
- 1 Mounting Kit for Link Equipment incl. 1 Frame NTPM, Frame for
Fan Unit and two FAN's (ca. 16 kg/ 35 Lbs)
- 1 Rack (ca. 60 kg/132 Lbs)
Sum: ca. 243 kg (536 Lbs)
Weight of Service1 Rack equipped with: - 2 Frames AC/DC and
- 2 Frames for Battery
Not possible: max. 3 Frames pro Rack / Shelter can be equipped.
Weight of Service1 Rack equipped with: - 1 Frame AC/DC incl. 6 AC/DC Modules (ca. 27 kg/60 Lbs)
- 1 Mounting Kit for Link Equipment incl. 2 Frame NTPM, Frame for
Fan Unit and two FAN's (ca. 21 kg/46 Lbs)
- 1 Rack (ca. 60kg/132 Lbs)
Sum: ca. 108 kg (238 Lbs)
Weight of Frame: Frame with Battery ca. 140 kg (309 Lbs)
FrameAC/DC with 6 AC/DC Modules ca. 27 kg (60 Lbs)
Frame with 4 CU's and 2 MUCO's ca. 40 kg (88 Lbs)
Frame with 4 ACOM's ca. 40 kg (88 Lbs))
1 HEX ca. 5.6 kg (12 Lbs)
Tab. 1.1 Technical Data
