V1.0
22
Disassemble the C35
A case opener is needed to disengage the latch of the C35 casing.
PHOTO 2.3 C35 CASE OPENER
The part number for this mandatory tool is F30032-P46-A1
Refer to ANNEX B of Chapter 3 for Service Equipment List.
STEP 1:
Remove the battery cover then the battery as shown in PHOTO 2.4
PHOTO 2.4 DISASSEMBLE C35 – STEP 1
