V1.0
5
key mechanism for personalizing the SIM in each user’s GSM phone. It is designed as a client-
server application. C35 series supports SAT Class 3 specification.
When active, the name of the service may appear in the menu, and there will be sub-menu if
more than one application is active. Figure 1.6 is the SAT icon.
FIGURE 1.4 SAT ICON
Extended GSM 900, E-GSM
This is a new standard that allows Network Operators to increase their capacity through an
extended frequency. The frequency range of E-GSM is as follows:
• Mobile Transmit: 880 – 915 MHz
• Mobile Receive: 925 – 960 MHz
C35 series is a GSM Phase 2 / Phase 2+ Dualband E-GSM / GSM 1800 mobile phone.
Built-in Modem.
C35i has an integrated modem for direct data communication using the data cable as shown in
Figure 1.5. C35 do not have the built-in soft modem for Data Service of GSM network.
FIGURE 1.5 DATA CABLE.
