Repair Documentation
Description of procedure
DIAGNOSIS
Visually check the bottom connector. Watch for dry joints!
REPAIR BY COMPONENT CHANGE
Use hot air blower remove defective bottom connector.
Avoid excessive heat!
Watch surrounding components!
Resolder new bottom connector afterwards.
REPAIR BY SW-BOOTING
Not possible!
TEST
Retest handset after repair.
List of needed material:
COMPONENTS
Bottom Connector X35
Part-Number: L36334-Z93-C262
JIGS AND TOOLS
Hot Air Blower
Soldering Iron
SPECIAL TOOLS
None
