Main menu > General func. > Summer-winter calculation
Parameter Value Function
Status
– Winter
– Summer
Status for summer/winter changeover:
– Winter operation is enabled.
– Summer operation is enabled.
Su/Wi input
– Winter
– Summer
Status of input on hardware side for changeover.
Go to page with all digital input settings to change
the input’s direction of control, for example change
the output signal.
– Winter operation enabled: Signal 0.
– Summer operation enabled: Signal 1.
Outs. temp. dampened Dampened outside air temperature.
Date/Time, summer *.* *:* Set date and time for changeover to summer
operation.
Example:
23:30 01.Apr ---> Changeover on April 1 at 11:30
PM.
– Asterisks only (*.* *:*): Changeover date is
not relevant; changeover occurs based on
temperature.
Permissible time entries:
*:* ---> 00:00
*:20 ---> 00:20
10:* ---> 10:00
– Date entry:
Allowed: 15.May
Not allowed by month: Odd/Even.
Date/Time, winter *.* *:* Set date and time for changeover to winter
operation.
Example:
10:40 PM 01.Oct ---> Changeover on October 1 at
10:40 PM.
Note: See summer Date / Time parameter.
Time constant 0…36000 [h] Time constant to calculate dampened (determined
over this period) outside air temperature. Set
this value for the short period to 0 to reset
the dampened or assume present outside air
temperature.
Outs temp summer -64...64 [°C] Changes over to summer operation when the
dampened outside air temperature is greater than
this value.
Outs temp winter -64...64 [°C] Changes over to winter operation when the
dampened outside air temperature is less than this
value.
Short Manual for Climatix Control System [v. 2.14.10, 2.14.20, 2.14.30 & 2.14.40]
SMCX.130215.02GB Page 8
