2. Functions
2.1 Overall functions
2.1.1 General
This section describes special functions that relate to the application as a whole.
Main menu > Overall functions.
Parameter Value Function
Summer-winter calculation
– Summer
– Winter
Displays present status for summer and winter
operation.
Go to page to parameterize summer/winter
changeover.
Manual operation
– Auto.
– Manual
Displays whether one of the outputs is not in auto
mode (intervention via HMI), a sensor is out of
service or the manual operation mode is not on
auto.
Go to page with all digital inputs, e.g. to set the
alarm class for enabled manual alarm.
– Auto mode: No element in manual mode or out of
service.
Manual mode: At least one element is in manual
operation or out of service.
Enable manual alarm
– No
– Yes
Enables an alarm if in Manual mode = Manual.
– No alarm will trip.
– Alarm enabled.
Enable comm. test The function is not available.
Communications test The function is not available.
2.1.2 Summer/winter changeover
None.
It decides whether the plant is operating in the summer or winter mode based on
various options (hardware input, date, temperature). This information is required (as
an option) to shut down humidification in summer, to changeover the Combi Coils
and to changeover temperature control (Tmp control mode = RmSplyC Su or
RtSplyC Su).
A hardware input enabled for the changeover (Main menu > Configuration >
Configuration 1 > Su/Wi input = Yes) has the highest priority (Signal 1 = Summer).
The temperature or date can affect the changeover depending on parameterization.
Both criteria must be met when both are enabled. There will be no changeover and
the plant will operate continuously in the winter mode if no criterion is enabled.
Parameter
Prerequisites
Function
