2.7 Temperature control
2.7.1 General
Displays only functions that are enabled in Configuration 1 or Configuration 2. All
other functions are hidden.
Main menu > Unit > Temp. control
Parameter Function
Act controlled tmp. Present temperature is used for control. Either supply air, room air or extract air
temperature, depending on the setting and control type.
Temp setpoints Go to setpoint page with all setpoints affected by temperature control,
e.g. comfort, economy, cascade min max, deviation alarm, summer-winter
compensation..
Cascade controller Displays heating and cooling setpoint. Go to cascade controller page with
detailed settings.
Min/max ctrlr sply Go to page for min/max ctrlr sply to parameterize the minimum and maximum
limit controller. You can use the existing supply air sensor to limit the minimum or
maximum allowable supply air temperature if purely room or return air control is
active..
Hrec damper Present value of the mixed air damper control. Go to parameter page for mixed
air damper control.
Heat recovery Present value for heat recovery control. Go to parameter page for heat recovery
control.
Heating Present value for heating register control. Go to parameter page for heating
register control..
El heating Present value for electric heating register control.
Go to parameter page for electric heating register control.
Cooling Present value for cooling register control for an additional register. Go to
parameter page for cooling register control.
Extra heating Present value for heating register for an extra register. Go to parameter page for
heating register control.
Extra el heating Present value for electric heating register control for an extra register. Go to
parameter page for electric heating register control.
Extra cooling Present value for cooling register control for an extra register. Go to parameter
page for cooling register control.
Fan heating Present value for fan heating sequence. Go to parameter page for fan heating
sequence.
Fan cooling Present value for fan cooling sequence. Go to parameter page for fan cooling
sequence.
Fan compensation Present value for fan temperature compensation. Go to parameter page for fan
temperature compensation.
Prerequisites
Parameterization
Short Manual for Climatix Control System [v. 2.14.10, 2.14.20, 2.14.30 & 2.14.40]
SMCX.130215.02GB Page 16

Siemens Climatix Series Specifications

General

Application	HVAC control
Communication Protocols	BACnet, Modbus, KNX
Inputs	Analog and digital inputs
Outputs	Analog and digital outputs
User Interface	web interface
Power Supply	24 V AC
Protection Class	IP20
Mounting	DIN rail mounting
