Fan clg dead zone 0…20 [°C] Controller dead zone: Setpoint = heating setpoint for
supply air – dead zone. If sequence is placed last: Supply
air cooling setpoint + dead zone.
Fan comp tmp stpt 0…99 [°C] Setpoint for room related fan compensation. See Fan
compensation; Function: Increase/decrease fan setpoint
based on room temperature.
Fan comp tmp functn Increase
Decrease
See Fan compensation; Function: Increase/decrease fan
setpoint based on room temperature.
Summer comp. --- Present value for summer compensation. Go to parameter
page for summer compensation.
Winter comp. --- Present value for summer compensation. Go to parameter
page for winter compensation.
Sply tmp dev alarm --- Present state for the setpoint/actual value for monitoring
the supply air pressure:
Passive: No alarm.
Active: Pending alarm.
Go to parameter page for supply air temperature
monitoring.
Room tmp dev alarm --- Present state for the setpoint/actual value for monitoring
the room temperature:
Passive: No alarm.
Active: Pending alarm.
Go to parameter page for room temperature monitoring
Supplementary temperature setpoints for enabling Step+temp.:
Comfort setpoint 0…99 [°C] Comfort setpoint. Available only when Setpoint type temp.
= +/– HalfDz.
Comfort cooling 0…99 [°C] Comfort setpoint for cooling. Available only when Setpoint
type temp. = HeatingCooling or Cooling–Dz.
Economy setpoint 0…99 [°C] Economy setpoint. Available only when Setpoint type
temp. = Sph + HalfDz.
Economy cooling 0…99 [°C] Economy setpoint for cooling. Available only when
Setpoint type temp. = HeatingCooling or Cooling–Dz.
Economy heating 0…99 [°C] Economy setpoint for heating. Available only when
Setpoint type temp. = HeatingCooling or Heating–Dz.
Economy dead zone 0…20 [°C] Economy dead zone. Available only when Setpoint type
temp. = Cooling–Dz, Heating + Dz or +/– HalfDz.
2.7.3 Freeze protection sensor performance test
Displays only the functions enabled in Config.
Main menu > Unit > Inputs > Temperatures > Freeze guard temp.test
Select -> Test
Enable alarm and freeze guard functions in the alarm list.
Confirm/Reset.
Prerequisites
Parameterization
Short Manual for Climatix Control System [v. 2.14.10, 2.14.20, 2.14.30 & 2.14.40]
SMCX.130215.02GB Page 18
