Siemens CPU 1512SP-1 PN User Manual

Article number 6ES7512-1DM03-0AB0
per integrated IO subsystem 
–
Inputs (volume) 8kbyte
–
Outputs (volume) 8kbyte
per CM/CP 
–
Inputs (volume) 8kbyte
–
Outputs (volume) 8kbyte
Subprocess images 
•
Number of subprocess images, max. 32
Address space per module 
•
Address space per module, max. 288byte; For input and output data respectively
Address space per station 
•
Address space per station, max. 2560byte; for central inputs and outputs;
depending on configuration; 2 048 bytes for ET
200SP modules + 512 bytes for ET 200AL mod
ules
Hardware configuration 
Number of distributed IO systems 32; A distributed I/O system is characterized not
only by the integration of distributed I/O via
PROFINET or PROFIBUS communication modules,
but also by the connection of I/O via AS-i master
modules or links (e.g. IE/PB-Link)
Number of DP masters 
•
Via CM 1
Number of IO Controllers 
•
integrated 1
•
Via CM 0
Rack 
•
Modules per rack, max. 82; CPU + 64 modules + server module (mount
ing width max. 1 m) + 16 ET 200AL modules
•
Quantity of operable ET 200SP modules,
max.
64
•
Quantity of operable ET 200AL modules,
max.
16
•
Number of lines, max. 1
PtP CM 
•
Number of PtP CMs the number of connectable PtP CMs is only lim
ited by the number of available slots
Time of day 
Clock 
•
Type Hardware clock
•
Backup time 6wk; At 40 °C ambient temperature, typically
•
Deviation per day, max. 10s; Typ.: 2 s
Operating hours counter 
31
Technical specifications
CPU 1512SP-1 PN (6ES7512-1DM03-0AB0)
Equipment Manual, 11/2022, A5E33591411-AE
