Siemens CPU 1512SP-1 PN User Manual

Article number 6ES7512-1DM03-0AB0
Interrupts/diagnostics/status information 
Diagnostics indication LED 
•
RUN/STOP LED Yes
•
ERROR LED Yes
•
MAINT LED Yes
•
Monitoring of the supply voltage (PWR-
LED)
Yes
•
Connection display LINK TX/RX Yes
Supported technology objects 
Motion Control Yes; Note: The number of technology objects
affects the cycle time of the PLC program; selec
tion guide via the TIA Selection Tool
•
Number of available Motion Control
resources for technology objects
1120
•
Required Motion Control resources
–
per speed-controlled axis 40
–
per positioning axis 80
–
per synchronous axis 160
–
per external encoder 80
–
per output cam 20
–
per cam track 160
–
per probe 40
•
Positioning axis
–
Number of positioning axes at motion
control cycle of 4 ms (typical value)
11
–
Number of positioning axes at motion
control cycle of 8 ms (typical value)
14
Controller
•
PID_Compact Yes; Universal PID controller with integrated
optimization
•
PID_3Step Yes; PID controller with integrated optimization
for valves
•
PID-Temp Yes; PID controller with integrated optimization
for temperature
Counting and measuring
•
High-speed counter Yes
Ambient conditions 
Ambient temperature during operation 
•
horizontal installation, min. -30°C; No condensation
•
horizontal installation, max. 60°C
•
vertical installation, min. -30°C; No condensation
•
vertical installation, max. 50°C
38
CPU 1512SP-1 PN (6ES7512-1DM03-0AB0)
Equipment Manual, 11/2022, A5E33591411-AE
Technical specifications
