Siemens CPU 1513-1 PN User Manual

CPU 1513-1 PN (6ES7513-1AM03-0AB0)
Equipment Manual, 11/2022, A5E40881673-AC
34
Interrupts, error messages, diagnostics and system
alarms
5
The status and error displays of the CPU1513-1PN are described below.
You will find additional information on "Interrupts" in the STEP7 online help.
You can find additional information on the topics of "Diagnostics" and "System alarms" in the
Diagnostics (http://support.automation.siemens.com/WW/view/en/59192926) function
manual.
5.1 Status and error display of the CPU
LED display
The figure below shows the CPU1513-1PN LEDs.




① RUN/STOP LED (yellow/green LED)
② ERROR LED (red LED)
③ MAINT LED (yellow LED)
④ LINK RX/TX LED for port X1P1 (yellow/green LED)
⑤ LINK RX/TX LED for port X1P2 (yellow/green LED)
⑥ STOP ACTIVE LED
Figure 5-1LED display of the CPU1513-1PN (without front panel)
