Siemens CPU 1513-1 PN User Manual

Meaning of the STOP ACTIVE LED
The following table shows the meaning of the STOP ACTIVE LED for the CPU1513‑1PN.
Table 5-3Meaning of the LEDs
STOP ACTIVE LED Meaning
LED lit yellow
The CPU is switched to "STOP" mode using the STOP button.
• As long as the STOP ACTIVE LED is lit up, switching the CPU to RUN mode is only possible
using the RUN button.
• The CPU can then no longer be set to RUN mode via the display operation or via online
functions. The state of the buttons is retained at power-off. If the CPU does not start up
automatically after a power-on, you have to keep the STOP button pressed during start-up
until the STOP ACTIVE LED is activated.
• If an automatic start-up is to be reliably prevented after a power-up, the STOP button has
to be kept pressed during the start-up of the CPU until the STOP ACTIVE LED is activated.
LED off
• The CPU is set to "STOP" mode using the display or programming device and not with the
STOP button on the device.
• The CPU is in RUN mode.
37
Interrupts, error messages, diagnostics and system alarms
5.1 Status and error display of the CPU
CPU 1513-1 PN (6ES7513-1AM03-0AB0)
Equipment Manual, 11/2022, A5E40881673-AC
