Siemens CU240E-2 - p0700[0...n] Command source selection; Cmd src sel; r0720[0...4] CU number of inputs and outputs; CU I;O count

Parameters
List of Parameters
1-90
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Description: Sets the command source.
Value: 0: No Macro
2: Terminals
6: Fieldbus
100: EAQ1
101: EAQ2
110: Set enable signals
120: FBM (fault, operation, signal)
130: Safety 0
131: Safety 1
140: CDS
150: MOP 1
152: MOP 3
160: Fix Setpoint 0
162: Fix Setpoint 2
170: Jog 1
181: 2 Wire type 2
182: 2 Wire type 3
183: 3 Wire type 1
184: 3 Wire type 2
Caution: When executing a specific macro, the corresponding programmed settings are made and become active.
Description: Displays the number of inputs and outputs
Index: [0] = Number of digital inputs
[1] = Number of digital outputs
[2] = Number of digital input/outputs bidirectional
[3] = Number of analog inputs
[4] = Number of analog outputs
p0700[0...n] Command source selection / Cmd src sel
CU240E-2 DP F Access level: 1 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: CDS, p0170
Units group: - Unit selection: -
Min Max Factory setting
0 184 0
r0720[0...4] CU number of inputs and outputs / CU I/O count
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: - Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - -
