Siemens CVMS2025-IR

Camera part and connector definition
Camera part definition
7
13
Siemens AG
A6V10334045
22.12.2011
7 Camera part and connector definition
7.1 Camera part definition
1
3
4
5
6
2
41,8
20,9
36,2
72,3
Ø6
Ø6
Unit: mm
1 Dome cover 4 Locking screw
2 Camera module 5 IR Led’s
3 Camera housing 6 Lens
7.2 Connector pin definition
