Configuration
9
Network settings
28
Siemens AG A6V10334045
22.12.2011
z Compression ratio
Set the quality of the delivered images. The size of the image files (JPEG files)
depends on the compression ratio.
– Low compression: This setting produces the highest image quality. The file
size increases.
– Mid compression: Standard setting.
– High compression: This setting produces the lowest image quality. The file
size decreases.
z Quality Value: When variable bit rate is selected as the rate control mode and
customized mode in Compression Ratio, the quality value can be selected
between 1 and 31.
– Low: default is 31
– Mid-low: default is 24
– Standard: default is 16
– Mid-high: default is 9
– High: default is 1
z Bit Rate: 6 modes including 256 kb, 512 kb, 1M, 2M, 3M, 4M.
z GOP: default is 25 (1 I frame plus 24 P frames). GOP can be selected between
1 and 64.
– 25fps:GOP 1~64
– 12fps: GOP 1~36
– 10fps: GOP 1~30
– 5fps: GOP 1~15
– 3fps: GOP 1~9
– 2fps: GOP 1~6
– 1fps: GOP 1~3
Cropping 1-5
The frame rate value for each cropping can be set between 1 and 5 fps.
9.2 Network settings
You can configure your basic camera settings, DDNS, FTP server, RTSP, HTTPS,
IEEE802.1X, SNMP & 3GPP by selecting "network setting" in the "Configuration"
menu.
