Installing the camera
8
Resolution
24
Siemens AG A6V10334045
22.12.2011
8.8 Resolution
There are different kinds of resolution depending on the function selected for the
network camera.
Item No. Limitation
If you choose VGA for stream 1, you have to choose between SVGA , VGA
and QVGA for the other streams. The resolution of the streams should be in
the same group.
Group 1 (VGA) SVGA VGA QVGA
Group 2 (D1) D1 CIF 2CIF 4CIF
Group 3 (1080p) 1080p
Group 4 (SXGA) SXGA VGA QVGA
1
Group 5 (720p) 720p D1
Resolution
2 The resolution of stream 3 follows stream 1 or stream 2
1 Cropping and E-zoom are mutually exclusive.
2 Cropping stream source is based on the largest resolution of normal
streams.
Total stream count with cropping is limited. Ex: If resolution is in group 1,
total maximum number of normal and cropping stream is 8.
Group 1 (VGA) (except
SVGA)
8
Cropping
3
Group 2 (D1) 6
1 Cropping and E-zoom are mutually exclusive. E-zoom
2 Only resolution in group 1 (except SVGA) and normal stream number less
than 2 (including number 2) can own E-zoom feature.
OSD &
Mask zone
1 Regular features of normal streams
