Configuration
Image parameter
9
39
Siemens AG
A6V10334045
22.12.2011
z Select “ON”, then click “Set Mask Zone” to start mask setting.
z Drag a mask rectangle on the screen. Click “OK” to complete the selection.
z Click “Save” to enable the mask setting.
Up to 8 masks can be set on the screen.
z EZOOM is not supported when cropping function is on.
z Privacy zone is not supported when cropping function is on.
z The cropping size of width and height must be multiple of 32. Ex: 320*160.
z The smallest cropping size will be 128*128.
z At least a resolution that should be set in VGA or D1.
9.3.3 Camera cropping settings
