Configuration
Image parameter
9
37
Siemens AG
A6V10334045
22.12.2011
1. OFF 2. Upper 2/3 (Area designation) 3. Lower 2/3 (Area designation)
4. Center 1/
3
(Area desi
g
nation) 5. Center 1/6 (Area desi
g
nation)
6. Left (Area desi
g
nation) 7. Ri
g
ht (Area desi
g
nation)
(The image level of shaded parts is maintained appropriate).
When OFF, rear light correction is not performed.
z Picture Flip:
When mounted upside down select “ON” to activate the flip function. With this
function you can flip an image upside down. Select "ON" to activate or "OFF" to
deactivate the flip function.
z Picture Mirror:
The selected image will be side-inverted. Select "ON" to activate or "OFF" to
deactivate the mirror function.
