Siemens FC2005 Installation Instruction

FC2005/FC901 SYSTEM CONNECTION DIAGRAM
Environm ental SLC Addressable Device Circuits
Operating temperature - 32 - 120°F (0 - 49°C) 32 VDC Max
Relative humidity - Up to 93% @ 90°F (32°C) Pow er limited
To be installed in a indoor dry protected environment only Supervised
Max. current: 0.07A(RMS)
Prim ary Pow er Supply Maximum w ire loop resistance: 50Ω
Input: 120VAC, 60 Hz or 220 VAC, 50 Hz Tw o Style 4 Class B or one Style 6 Class A circuit
@ 2.0A Max. Max. 50 addressable devices
Supervised City Tie Circuits
Output: 26VDC @ 6.5A Max. Supply Input:
Max current: 6.5A (2 hours Max.) Voltage: 26 VDC
Filtered and Regulated 18 – 28 VDC for battery
Current: Max. 0.4A
Secondary Pow er Supply Supervised
24V lead-acid battery set Output:
Max. charged voltage: 27.8 VDC City Tie-Output 1
Automatic low battery disconnect voltage: 19.2±0.1VDC Normal output voltage: 19-28VDC (open circuit condition)
Max. charge current: 0.45A Supervisory current: 1mA
Battery capacity:12AH to 18AH Maximum trip current: 400mA
Supervised Maximum coil plus w ire resistance: 22.5Ω
Auxiliary Pow er Outputs Leased line-Output 1
- Non-resettable pow er output Normal output voltage:19-28VDC (open circuit condition)
Pow er limited Trouble output voltage: 0V
Alarm status: 0.75A
Alarm output voltage:-(19-28)VDC (open circuit condition)
Normal stand by: 0.05A Maximum w ire resistance: 2-5KΩ
Voltage: 19 to 28VDC Maximum short circuit current: 25mA
Ripple: 0.1 VAC
Special Application Leased line-Output 2
Normal output voltage: 19-28VDC (open circuit condition)
- Resettable pow er output Supervisory output voltage: -(19-28)VDC (open circuit condition)
Pow er limited Maximum w ire resistance: 2-5KΩ
Alarm status: 0.75A Maximum short circuit current: 25mA
Normal stand by: 0.05A
Voltage: 19 to 28VDC DACT Circuits
Ripple: 0.1 VAC Pow er limited
Special Application Supervised for short or open circuit conditions
Compliance to FCC part 68
Status Relays Support RJ31X connection
Non-pow er limited Compatible Digital Alarm Communication Receiver (DACR) list,
One programmable relay
Three non-programmable relays: Trouble, Supervisory, Alarm
Contact rating: 2A, 30VDC maximum
Form C contact
Notification Appliance Circuits
Pow er limited
Supervised
Current Draw Maximum Line Resistance
2.5A 3.2Ω
2.0A 4.0Ω
1.5A 5.3Ω
1.0A 8.0Ω
0.5A 16.0Ω
Alarm voltage: 16 to 32VDC
Maximum ripple: 0.1VAC
Used for special application only
Tw o Style Y/Class B or one Style Z/Class A
Total Max. Current: 2.5A
Device m odule Manufacture
MX8000 Honeyw ell
DACT compatibility list
CAUTION – To reduce the risk of fire, use only No. 26 AWG
or larger telecommunication line cord.
FC2005/FC901 SYSTEM GENERAL SPECIFICATION
Document ID: A5Q00039713A
Page 7/12 02.2012
Fire Safety & Security Products
Building Technologies
FC2005/FC901 installation instruction

Siemens FC2005 Specifications

General

Brand	Siemens
Model	FC2005
Category	Control Panel
Language	English
