Test and measuring equipment
10
Siemens Building Technologies 007833_a_en_--.doc
Fire & Security Products 03.2004
3 Test and measuring equipment
Multimeter
Accuracy ≤ 2%
Internal resistance ≥ 20kΩ
Measuring ranges 1 to 500VAC / DC, 100mA to 5ADC, 10Ω to10MΩ
Battery test set
Load resistor 5Ω
Maintenance-PC
System requirements see document 007895
Detector tester
Depending on detector type / detector system
For all detectors OP620, OH620 and HI62x
– Detector exchanger DZ1191
– Detector exchanger and tester DZ1193
For smoke detectors OP… and OH…
– Detector tester RE6 and test gas
For heat detectors HI…
– Detector tester RE6T
For smoke detectors DLO1191
– Detector tester RE10
– Adjustment set DZL1191
For flame detectors DF1191/92
– Test lamp LE3, StabexHF for explosion hazard areas
Line tester
Depending on detector type
For collective detector lines
– Alarm test probe (5.6V Zener diode with 220Ω resistor)
For addressable detector lines
– Line test unit DZ1131
