29 Installation checklist
The following list serves as a checklist and task list for the installation personnel. The list contains all the
components that can be installed.
Type
Component / task
Notes
Complete
FCM2017-UM Assemble enclosure Inner doors, outer door, window (Marine
Enclosure)
FCM2018-U2
FCM2019-U2
FCM2035-U2
FCM2018-U3
FCM2019-U3
FCM2035-U3
Install operating unit
FCI2016-U1
FCI2017-U1
Install the periphery board
FP2011-U1
Install the power supply (170 W)
FHA2031-U1 Install the DIN Rail kit
FN2001-U1
Install the network module
(SAFEDLINK)
Ensure correct installation site
FCI2011-U1
Install the NAC module (1A/2B)
Same slot as releasing module
XCI2001-U1
Install releasing module
Same slot as NAC module
FCA2016-U1
Install RS-485 module
Max. 2 modules
FT2014-R2/-
R3/-U2/-U3
FT2015- R2/-
R3/-U2/-U3
Install the Remote Display Terminal
R2 = Red, Desigo
R3 = Red, Cerberus PRO
U2 = Black, Desigo
U3 = Black, Cerberus PRO
BP-62
Marine Batteries
Only connect when commissioning
Due date:
Ordering unit:
Date
