FS20 Marine Fire Detection Control Panel
28
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
6 FCM2018-U2 / FCM2019-U2 / FCM2018-U3 /
FCM2019-U3 / FCM2035-U2 / FCM2035-U3,
Operating Units
View of FCM2018 operating unit
The operating unit is Person Machine Interface (PMI) of the FS20 Panel. It is installed on upper
portion of the cabinet.
3 3
1
2
3 3
4
Rear view of operating unit FCM2018 with Operating Unit & its Mainboard FCM2027
1 Operating unit carrier plate
2 System Operating Units & Mainboard FCM2027
3 Mounting holes for installing on the inner door
4 Space for LED module for operating unit (+LED) FCM2019-U2
