CHAPTER 3 | FCM2041-U3 OPERATOR INTERFACE MANUAL
MAINTENANCE MODE
3-11
Touch the box that represents the new ASD setting and press the OK soft key to
select the changes. The Change ASD screen (Figure 3-18) displays to verify that the
new setting has been selected.
10:53
Category text information
Menu:Maint:Control:ChangeASD
PHY:FireFinder@1, DLC@1, HFP11@2
Cancel
CHANGE ASD
AT: FireFinder@1, DLC@1, HFP11@2
# ASD Devices: 1
SETTINGS:
FROM: Disable
TO: Office
Execute
Figure 3-18
Change ASD Setting Status Screen
At this point, the ASD setting has not been changed.
Press the Execute soft key to change the ASD setting.
Control - Change Sens Use the Change Sensitivity feature to change the sensitivity settings at the OI for any
chosen DLC, XDLC, or MLC device. Effective with PMI Rev. 8.01, the sensitivity
settings for DLC/XDLC devices are shown as High 4, High 3, High 2, High 1, Normal,
Low 1 or Low 2. They are no longer set using percent/ft. obscuration. MLC device
sensitivity settings are shown as High3, High2, High1, Normal, Low1, Low2 or Low3.
Refer to the Device Sensitivity %/Foot Settings Table for more information.
The sensitivity of VESDA devices cannot be changed by the user.
SGNITTESTOOF/%YTIVITISNESECIVED
SECIVEDCLDSECIVEDCLM
gnitteS
11-PFH
-/129HO
-4TODF
-9PO/12
-ODF/12
124
-49HOO
-O
DF/1
-/144TO
-9CHOO
-ODF/14
144CTO
gnitteSxxPFxPLIxILIx06DI
4hgiH
tf/%54.2
3hgiHtf/%85.2tf/%52.2tf/%00.1tf/%81.1
3hgiH
tf/%95.2
2hgiHtf/%57.2tf/%54.2tf/%21.1tf/%42.1
2hgiHtf/%27.21hgiHtf/%68.2tf/%57.2tf/%42.1tf/%03.1
1hgiH
tf/%68.2tf%0
4.1tf%05.2
lamroNtf/%00.3tf/%00.3tf/%63.1tf/%63.1
lamroN
tf/%00.3tf%08.1tf%00.3
1woLtf/%31.3tf/%62.3tf/%84.1tf/%24.1
1woLtf/%31.3tf%03.2tf%05.32woLtf/%62.3tf/%05.3tf/%06.1tf/%84.1
2woLtf/%72.33woLtf/%04.3tf/%57.3tf/%27.1tf/%35.1
While in Maintenance mode, navigate to the desired module/loop or device by
pressing the More Info/+ or
(FCM2041-U3) buttons.
Change Sensitivity operations can only be performed at the device level. These
operations will appear grayed out on the OI when the system is set at any other
