BASIC OPERATION 1-1
INTRODUCTION The FCM2041-U3 is the primary user interface for the Cerberus PRO Modular
system. When the FCM2041-U3 is installed, the display, LEDs and control keys/
buttons are visible from behind a locked door. Unlock and open the door to gain
access to those keys and buttons.
From the FCM2041-U3 the operator can acknowledge events, control the system
notification appliance circuits and reset the system. Detailed information about the
nature and location of events can also be displayed.
The FCM2041-U3 contains the site specific program as developed in the Zeus
programming tool. All system logic and supervision is provided by the controller in the
Operator Interface (OI). The FCM2041-U3 and the Zeus programming tool require
compatible firmware/software. The tool will give a warning if the user attempts to use
incompatible software to configure a system.
The FCM2041-U3 contains a VGA LCD, Touch Screen and LEDs for displaying system
status. An audible sounds when there are unacknowledged events on the OI. This
screen is surrounded by keys that are used to control the displayed information and
to navigate through these screens. If more items are present than can be displayed
on a single screen, a scroll bar appears to the right of the list. Press the up and down
navigation buttons to the right of the LCD to move through the list. The selected
listing is highlighted in the display. Buttons are also provided to obtain help and to
enter into the menu features of the FCM2041-U3 (See Figure 1-1).
The FCM2041-U3 can display up to nine types, which are configurable in Zeus. In
“legacy mode” (configurable at the node level in Zeus), a FCM2041-U3 running
firmware version 12 or above will display only the four event types that are valid for
the PMI (Alarm, Supervisory, Security, and Trouble). This allows a FCM2041-U3 to be
installed as a replacement for a PMI.
