3
Structure and function
Overview
20
Building Technologies A6V10334410_h_en_--
Fire Safety 2015-09-29
Properties
Patented technology
Can be used with Siemens FDnet/C-NET loop (with optional FDCC221S
installed)
Extended optical detection thanks to dual wavelengths (blue and infrared)
Configuration via USB or FDCC221S (option)
'Out-of-the-box' installation and commissioning
Early detection of a wider spectrum of particle sizes in the air
Software 'FXS2055 ASD Asyst Tool' and pipe configuration supported
Programmable alarm thresholds
Unique dust-resistant detection chamber
Intuitive front indicator for airflow and smoke value
Normalization of the smoke value
Normalization of the airflow
Access to service functions
Different event protocols
Offline/online configuration supported
FDA241, monitoring area of up to 800
FDA221, monitoring area of up to 500
4…20 mA output
Cleaning function (with FDA241 only)
Firmware can be updated locally
3.1.1 Details for ordering
Type
Order no.
Designation
FDA241 S54333-F17-A1 Aspirating smoke detector (8H)
FDA221 S54333-F15-A1 Aspirating smoke detector (5S)
