Page #85 background imageLoading...
Page #85 background image
Commissioning
7
Functional testing of the system
85
Building Technologies A6V10334410_h_en_--
Fire Safety 2015-09-29
Testing with alarm transmission/triggering of an alarm
Communication transponder FDCC221S is not installed.
The relay outputs are activated.
A smoke stick/aerosol spray is available.
A connected fire detection installation and the connected alarm devices must
be configured as appropriate for the test.
1. Move the smoke/aerosol toward an aspirating hole in the pipe system.
2. If you wish to measure the response time at the same time, please note the
following:
Select an aspirating hole that is a long distance away if you wish to test the
response time.
Measure how long it takes for the smoke indicator to display 'fire alarm 1'.
The time measured is the response time.
3. Check whether an alarm is indicated on the front indicator and whether the
buzzer is activated. [➙ 24]
4. Press the button briefly to switch off the buzzer.
5. Check the following:
The alarm devices connected via relays indicate an alarm.
The 'Smoke 4…20 mA' analog output indicates the relevant current. [➙ 66]
6. Wait until the smoke indicator has dropped to no more than 5 LEDs.
7. With self-retention activated:
Open the housing cover. [➙ 46]
Press the
button to reset the detector status. [➙ 28]
Close the housing cover.
The fault indicator goes out.
That is the end of the test.
