Siemens HCP User Manual

Siemens Industry, Inc.
Building Technologies Division
P/N 315-034860-132
COMPATIBILITY The following minimum revisions are required for proper operation of the HCP:
:METSYSSLX:METSYS052-SFMETSYS02SF
CLD0000.00.40CLD-SF05.1
OGISED
IMP0000.00.40CAN81.20502/5202CFxx.xx.14
21-CSP0000.00.70
LENAP0.50502/5202VFxx.xx.06
04-CAZ
0000.80.20
*0000.80.031
SUEZ9100.00.40
ORPSUREBREC
429/229CFxx.xx.14
429/229VFxx.xx.06
htiwelbitapmocTONera0000.42.20.veRdna0000.12.20.veR,0000.90.031/0000.
90.20.veR04-CAZ*
.0000.01.031/0000.01.20.veRro0000.80.031/0000.80.20.veRottreveR.PCHeht
WIRING
Remove all system power before installation, first battery then AC. (To power up,
connect the AC first, then the battery.)
Power down the 24 VDC power supply and the input source (ZAC, etc.) before
installing the HCP.
All wiring must comply with national and local codes. All wire must be 18 AWG
minimum, 12 AWG maximum.
Device Loops The HCP communicates with the FireFinder-XLS/FS-250/Desigo FC2025/2050,
FV2025/2050/Cerberus PRO FC922/924, FV922/924 Systems through its addressable
device loops. These loops are connected to the DLC via terminal blocks on the CC-5
or CC-2 cardcage (XLS) or to the FS-DLC via TB3 on the FS-MB/FS-MB2 main board
(FS-250). They may be wired Class A (Style 6) or Class B (Style 4). Figure 2 shows
both wiring types and the connections to the DLC. See the DLC Installation Instruc-
tions, P/N 315-033090, for more information. Figure 3 shows both wiring types and
connections to the FS-DLC. See the FS-250 Installation, Operation and Maintenance
Manual, P/N 315-049353, for more information. Figure 4 shows both wiring types and
connections to the Periphery boards. See the Desigo FC2025/2050 FV2025/2050
Configuration Manual, Document ID A6V10315023, for more information. Figure 5
shows both wiring types and connections to the Periphery boards. See the Cerberus
PRO FC922/924 FV922/924 Configuration Manual, Document ID A6V10333423, for
more information.
HCP Power Supply For FireFinder-XLS Systems, compatible power supplies for the HCP are the PSC-12,
PSX-12, and PAD-4. Wiring should be connected to TB3 on the PSC-12 and PSX-12, or
the auxiliary power supply on the PAD-4.
For FS-250 Systems, the HCP is powered by the NAC circuits and PAD-4. Wiring
should be connected to the NAC circuits on the main board or the auxiliary power
supply on the PAD-4.
