lan2de.c01
A31003-K5020-S100-6-7620
Service Manual
1-3
For internal use only Introduction
1.3 Service information
The unique worldwide Ethernet address (MAC address) is a factory default and can-
not be modified.
Card recognition is performed automatically in Hicom 150 E Office/Hicom 150 H,
Point/Com/Pro. HiPath HG 1500 is installed as an individual board type in Hicom 150
E Office/Hicom 150 H, Point/Com/Pro.
The following items can be administered in Hicom:
●
S0 station
●
Xpress clients
●
IP network lines
●
numbering scheme
●
associated dialing
●
answer group (PC telephone)
●
call forwarding (PC to fax)
●
suppression of incoming 0
●
CSTA interface
Details on the initial startup and on accessing the board can be found in the HiPath
HG 1500 Administration Manual.
A separate tool (Assistant Xpress @LAN/HG 1500) that can also be used by the cus-
tomer or the LAN administrator is provided for entering and modifying data, e.g. the
IP address of the customer LAN or ISDN numbers assigned to a communication part-
ner. The data is permanently stored in HiPath HG 1500. HiPath HG 1500 Assistant
also facilitates the storage of a corresponding configuration file. This can then be re-
trieved if a board needs replacing. The tool also provides a facility for querying the
software version. Access to HiPath HG 1500 administration is password-protected.
This password can be changed; however, the Hicom password concept applies; see
Ta bl e 1 - 1 .
Note that only the user and Hicom passwords are allowed.
A simple functional test can be performed directly at the customer PC or on a service
PC with a network card, vCAPI driver and a CAPI-based application.
APS transfer for the HiPath HG 1500 board is usually performed via the LAN using
the Assistant or, in exceptional circumstances, via the V.24 interface using the Load-
er.
Cable with reference number S30122-X5468-X3 (see also
Section 2.1.1.1 or
Section 2.1.2.1) is used for the V.24 port of the HiPath HG 1500 board.
